Name: Straight Male Header Connector 11 Pin Pitch 3.96mm Tin Plated V-0 Material
Brand: Dongguan JVT Connectors Co., Ltd
SKU: JVT1120WNO-10SN-D
Availability: InStock

Dom Produkty PCB Board Connector

Straight Male Header Connector 11 Pin Pitch 3.96mm Tin Plated V-0 Material

Szczegóły Produktu:

Place of Origin:	China
Nazwa handlowa:	JVT
Orzecznictwo:	ISO9001/SGS/UL/ROHS/Reach
Model Number:	JVT1120WNO-10SN-D

Zapłata:

Minimum Order Quantity:	1000 PCS
Cena:	negocjowalne
Packaging Details:	PE bag packing +outer carton
Delivery Time:	7-10 working days
Payment Terms:	T/T or Western Union
Supply Ability:	300000 per month

Skontaktuj się teraz

Szczegółowy opis produktu

Category:

PCB Board Wafer

Application:

PCB Board Connector

Orientation:

Vertical

contact:

Podkreślić:

pcb socket connector

pcb header connectors

straight male header connector ,11pin ,pitch 3.96mm ,tin plated ,V-0 materail

Material Specification:

Terminal: Phosphor Bronze or Brass ,Tin plated

Housing: PA66,UL94V-0

Wafer: Nylon 66 UL94V-0

PIN: Brass ,Tin plated

Datasheet (PDF) & Other Documents Download center:

1.JVT1120WN0-XXSNX-D.pdf

VH 3.96mm Pitch straight header for PCB Board Electrical Connectors in White Color With Five Pins

Product Profile

Series	VH connector
Category	Wire to Board Crimp style Connectors
Type	Disconnectable type Crimp style, Compact type, With locking device
Feature	With secure locking device

Straight Male Header Connector 11 Pin Pitch 3.96mm Tin Plated V-0 Material

Standard Specification:

This small, field-proven connector for PC boards is reliable and has a large current carrying capacity. It can be used with a wide variety of signal, power supply, and output circuits that appear in consumer electronic products.

JVT offer a complete range of board to board and board to wire connectors including :pin header ,mini jumpers,female header ,PCB Multipole and housing a wide range of applications including :industrial ,Medical and automotive .

All are offered with small moq's ,the majority being stocked items .

Payment Details:

Payment Terms:T/T or Western Union

Minimum Order:1000 Pieces
